Description
Meet the bike in between nothing. Leaving no rider wanting. Master of the climb, the bomb, the rain and the air. The unequivocal. The rule crusher. The trend buster. No rig can rule all, but this one can absolutely rule. The mountain bike.
This is the mountain bike you reach for when the trail is untamed and unrelenting, in both directions. "Trail bike" is a term that gets used pretty liberally in the industry, so we designed the SB140 to be even better suited to go deep and find out what's on the other side.
All C2 Bikes Now Upgraded to SRAM X01 Components
Yeti has upgraded all C2 bikes to feature the high-performance SRAM X01 (Cable) drivetrain. This includes the X01 Cassette, Shifter, Derailleur, X1 Carbon Cranks, and GX Chain
Specification
| C2 LR | C3 LR | |
| TRAVEL | TRAVEL 140MM (5.5") | TRAVEL 140MM (5.5") |
| MATERIAL | MATERIAL C/SERIES | MATERIAL C/SERIES |
| FORK | FORK FOX PERFORMANCE 36/160MM | FORK FOX PERFORMANCE 36/160MM |
| SHOCK | SHOCK FOX PERFORMANCE FLOAT X | SHOCK FOX PERFORMANCE FLOAT X |
| WHEELSET | WHEELSET DT SWISS M1900 30MM | WHEELSET DT SWISS M1900 30MM |
| REAR DER | REAR DER SRAM GX EAGLE | REAR DER SRAM GX EAGLE AXS TRANSMISSION |
| SHIFT | SHIFT SRAM GX EAGLE | SHIFT SRAM AXS POD CONTROLLER |
| CRANK | CRANK SRAM GX EAGLE 30T 170MM | CRANK SRAM GX EAGLE TRANSMISSION 30T 170MM |
| BB | BB SRAM DUB BSA 73 | BB SRAM DUB BSA 73 |
| CASSETTE | CASSETTE SRAM GX EAGLE 1275 10-52 | CASSETTE SRAM GX EAGLE TRANSMISSION 10-52 |
| CHAIN | CHAIN SRAM GX EAGLE | CHAIN SRAM GX EAGLE TRANSMISSION FLATTOP |
| BRAKES | BRAKES SRAM CODE R | BRAKES SRAM CODE R |
| ROTOR | ROTOR F/R SRAM CENTERLINE 200/SRAM CENTERLINE 180 | ROTOR F/R SRAM CENTERLINE 200/SRAM CENTERLINE 180 |
| POST | POST ONEUP DROPPER POST 31.6MM / SM: 150MM, MD: 180MM, LG-XXL: 210MM | POST ONEUP DROPPER POST 31.6MM / SM: 150MM, MD: 180MM, LG-XXL: 210MM |
| TIRE (F) | TIRE (F) MAXXIS MINION DHF 2.5 EXO | TIRE (F) MAXXIS MINION DHF 2.5 EXO |
| TIRE (R) | TIRE (R) MAXXIS MINION DHR II 2.4 EXO | TIRE (R) MAXXIS MINION DHR II 2.4 EXO |
| HEADSET | HEADSET CANE CREEK 40 INTEGRATED | HEADSET CANE CREEK 40 INTEGRATED |
| BAR | BAR BURGTEC RIDE WIDE ALLOY ENDURO 35X780MM | BAR BURGTEC RIDE WIDE ALLOY ENDURO 35X780MM |
| STEM | STEM BURGTEC ENDURO MK3 35X50MM | STEM BURGTEC ENDURO MK3 35X50MM |
| GRIPS | GRIPS ODI ELITE PRO | GRIPS ODI ELITE PRO |
| SADDLE | SADDLE SILVERADO CUSTOM | SADDLE SILVERADO CUSTOM |
Geometry
| SM | MD | LG | XL | 2XL | ||
| A | SEAT TUBE LENGTH | 14.4 | 15.7 | 17.3 | 18.5 | 19.1 |
| B | EFFECTIVE TOPTUBE LENGTH | 22.5 | 23.7 | 24.5 | 25.6 | 26.4 |
| C | HEADTUBE ANGLE | 65.4 | 65.4 | 65.4 | 65.4 | 65.4 |
| D | EFF. SEAT TUBE ANGLE | 77.5 | 77.5 | 77.5 | 77.4 | 77.4 |
| E | ACTUAL SEAT TUBE ANGLE | 72.2 | 72.6 | 72.8 | 73.2 | 73.7 |
| F | CHAINSTAY LENGTH | 17.2 | 17.2 | 17.3 | 17.4 | 17.5 |
| G | WHEELBASE | 46.6 | 47.9 | 48.9 | 50.1 | 51.2 |
| H | ESTIMATED BB HEIGHT | 13.3 | 13.3 | 13.3 | 13.3 | 13.3 |
| I | STANDOVER | 28.4 | 28.7 | 28.9 | 28.9 | 29.1 |
| J | HEADTUBE LENGTH | 3.6 | 3.7 | 4.0 | 4.4 | 5.3 |
| K | FORK AXLE TO CROWN | 22.2 | 22.2 | 22.2 | 22.2 | 22.2 |
| L | FORK OFFSET | 1.7 | 1.7 | 1.7 | 1.7 | 1.7 |
| M | STACK | 24.2 | 24.3 | 24.5 | 24.9 | 25.6 |
| N | REACH | 17.1 | 18.3 | 19.1 | 20.1 | 20.7 |
| O | FRONT CENTER | 29.5 | 30.7 | 31.6 | 32.7 | 33.7 |
| P | Vertical Fork Travel | 5.4 | 5.4 | 5.4 | 5.4 | 5.4 |
Size
| SM | 5'1" - 5'7" |
| MD | 5'5 - 5'11" |
| LG | 5'10" - 6'3" |
| XL | 6'1 - 6'7" |
| 2XL | 6'5 - 6'11" |
