GRX DUAL CONTROL LEVER 2X12s
ST-RX820-R
PRODUCT SPECIFICATION:
Model No
ST-RX820-R
Series
GRX
Bracket cover color
1 x Standard
Shifter type
DUAL CONTROL LEVER
Shift lever
Rear speeds x 12
Shift lever cable
Outer casing|Lever side
OT-SP41
Outer casing|Rear derailleur side
OT-RS900
Inner cable|Polymer-coated cable
GRX DUAL CONTROL LEVER 2X12s
ST-RX820-L
PRODUCT SPECIFICATION:
Model No
ST-RX820-L
Series
GRX
Bracket cover color
1 x Standard
Shifter type
DUAL CONTROL LEVER
Shift lever
Front speeds x 2
Shift lever cable
Outer casing|Lever side
OT-SP41
Inner cable|Polymer-coated cable
GRX CRANKSET - 2X12s
FC-RX820-2
PRODUCT SPECIFICATION:
Model No
FC-RX820-2
Series
GRX
Rear speeds
12
Compatible chain
HG 12-speed
Chain line (mm)
47
P.C.D. (mm)
110/80
GRX FRONT DERAILLEUR 2X12s
FD-RX820
PRODUCT SPECIFICATION:
Model No
FD-RX820
Series
GRX
Front speeds
2
Rear speeds
12
Compatible chain
HG 12-speed
Action
Down swing
GRX REAR DERAILLEUR 12s (FOR 11-34/36T)
RD-RX820
PRODUCT SPECIFICATION:
Model No
RD-RX820
Series
GRX
Rear speeds
12
Compatible chain
HG 12-speed
RD construction
SHIMANO SHADOW RD
Mount
Direct attachment (conventional)
Direct mount
HG CASSETTE 12s
CS-HG710-12
PRODUCT SPECIFICATION:
Model No
CS-HG710-12
Series
SHIMANO
Type
HG
Rear speeds
12
Compatible chain
HG 12-speed
Combination name (Group name)
11-36T
HYPERGLIDE CHAIN 12s
CN-M8100
PRODUCT SPECIFICATION:
Model No
CN-M8100
Series
SHIMANO
Type
HG 12-speed
E-BIKE rear derailleur system compatible
Pin link plate
Gray
Roller link plate
Chromizing
GRX - FLAT MOUNT - BRAKE CALIPER
BR-RX820
PRODUCT SPECIFICATION:
Model No
BR-RX820
Series
GRX
Brake type
Hydraulic disc brake
Brake hose (kit)
SM-BH90-JK-SSR
Hose joint
Straight
Brake hose color (kit)
1 x Black
DISC BRAKE ROTOR ICE TECHNOLOGIES FREEZA
RT-MT800
PRODUCT SPECIFICATION:
Model No
RT-MT800
Series
SHIMANO
CENTER LOCK
ICE TECHNOLOGIES
ICE TECHNOLOGIES FREEZA
Outside diameter (mm)
160
140
SHIMANO SM-BBR60 BSA BOTTOM BRACKET
SM-BBR60
PRODUCT SPECIFICATION:
Model No
SM-BBR60
Series
SHIMANO
Size
68 mm
Colour
Black
Weight
79 grams
