Smart integrated fuel and hydration storage makes it simple and stress-free to stay strong without leaving your aero position. The Top Tube IsoSpeed takes the edge off rough roads and is damped with an elastomer so it rebounds in a smooth, controlled, stable motion. Easy build, easy travel, fast assembly makes it easier to travel to races. The all-new wireless Dura-Ace/Ultegra Di2 delivers faster, smoother and more responsive shifts than ever.
Specs.
Frame | 800 Series OCLV Carbon, KVF (Kammtail Virtual Foil) tube shape, T47 BB, integrated Bento box, integrated downtube storage |
|---|---|
| Fork | |
| Frame fit | Triathlon |
| Weight | M - 8.97 kg/19.78 lb |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
| Battery | Shimano BT-DN300 |
|---|---|
| Charger | Charging cable included |
| Shifter | Shimano Dura-Ace hydraulic disc, R9180 Di2 lever, R9270 calliper, 160mm rotor |
|---|---|
| Front derailleur | Shimano Ultegra R8150 Di2, braze-on, down swing |
| Rear derailleur | Shimano Ultegra R8150 Di2, 34T max cog |
| *Crank | Size:S, M, L Shimano Ultegra R8100, 52/36, 170 mm length |
| Size:S Shimano Ultegra R8100, 52/36, 165 mm length | |
| Size:M, L, XL Shimano Ultegra R8100, 52/36, 172.5 mm length | |
| Size:XL Shimano Ultegra R8100, 52/36, 175 mm length | |
| Bottom bracket | |
| Cassette | Shimano Ultegra R8100, 11-30, 12-speed |
| Chain | Shimano Ultegra/XT M8100, 12-speed |
| Max. chainring size | 1x: 58T, 2x: 55/44 |
| Wheel front | Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, 100x12mm thru axle |
|---|---|
| *Wheel rear | Size:S, M, L, XL |
| Size:S, M, L, XL | |
| Skewer front | |
| Skewer rear | |
| Tyre | |
| Max tyre size | 28mm rear, 25mm front |
| Saddle | |
|---|---|
| *Seatpost | Size:S |
| Size:M, L, XL | |
| *Handlebar part | Size:S, M |
| Size:S, M, L, XL | |
| Size:S | |
| Size:M, L, XL | |
| Size:L, XL | |
| Handlebar/stem (integrated) | |
| Handlebar tape | Bontrager Supertack Perf tape |
| Brake | Shimano Dura-Ace hydraulic disc |
| Brake rotor | Shimano CL800, CentreLock, 160 mm |
| Rotor size | Max brake rotor sizes: 160 mm front and rear |
| Cage | Speed Concept Downtube Bottle Cage |
|---|---|
| Bottle |
Trek reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
