Stumpjumper 15 hlins Coil 2025

Stumpjumper 15 hlins Coil 2025

$ 57.93

$ 219.56

Unavailable
Stumpjumper 15 hlins Coil 2025

Stumpjumper 15 hlins Coil 2025

$ 57.93

$ 219.56

Size:
  • S2
  • S3
  • S4
  • S5
  • S6
Unavailable
Please select combo product attributes
The combo subtotal is $,SAVE$

Product Details

Description

Stumpjumper 15 is here to obliterate every trade-off in the trail game. Devour bumps like a big bike? Check. Short-travel control, playfulness, and efficiency? Double check. How about a heaping helping of personalization to make it perfect for the only rider who really mattersyou? Check, check, check.

KINEMATICS PERFECTED: As the quintessential trail bike, Stumpjumper 15 balances efficiency and optimal bump force management. For the anti-squat on Stumpjumper 15, we struck a balance between the previous Stumpjumper and Stumpjumper EVO, as both had excellent pedaling characteristics.

HONED GEOMETRY: This bikes geometry delivers big bike capability when you need it, a nimble feel in tight sections, and lively, efficient climbing manners. The generous cockpit centers you on the bike, optimizing traction and corner control. The low bottom bracket, slack head tube angle, and optimized fork offset keep things stable in the rough.

RIDE YOUR WAY: The Stumpjumper 15 seamlessly integrates benchmark geo adjustability, making it the most personalizable trail bike ever. Six distinct geometry settings allow you to hone performance for any style, any terrain. Head angle and bottom bracket can be fine-tuned for stability or clearance.

FORM FOLLOWS FUN: We can make a frame as stiff as we want, but theres such a thing as too stiff. To be one with the bike requires engineered compliance in the frame. We engineered the FACT 11M carbon and M5 Alloy chassisfront end, rear end, and the link between themas a single unit that hits the stiffness target we established for trail riding.

WHEEL SIZE: All coil-sprung models are mixed wheels. All models in S1 and S2 sizes come with mixed wheels to ensure the perfect geo for smaller riders.

WHEEL CHOICE: With our aftermarket link shock links, you can choose between big wheels front and rear or mix things up with a 27.5 rear for a more responsive and playful ride. No matter what you choose, geometry is unaffected.

CARRY IT ALL: SWAT 4.0 on Stumpjumper 15 elevates downtube storage, an innovation we pioneered. Its the smoothest operating, most weather-resistant, flush-mounted system ever.

MORE RELENTLESS THAN YOU: Our full suspension bikes are built to be relentless, designed to endure years of hard riding and backed by the best support and policies to keep you on the trail. Our unbeatable lifetime, no-questions-asked replacement of suspension pivot bearings to the original owner is just one way we've got you covered.

  • Lightweight FACT 11m carbon chassis and rear-end
  • Incredibly tough Roval Traverse wheels with DT Swiss 370 hub
  • Premium suspension support from an hlins TTX 22 M Coil, Ride Dynamics tuned
  • Plow through anything with a 160mm hlins RXF38 M.2 29 fork
  • Reliable and smooth shifting from SRAM GX Eagle AXS T-Type drivetrain
  • Powerful brakes with great hand feel thanks to TRP DH-R EVO 4-piston brakes
  • Adjustable travel PNW LOAM dropper post
  • Lifetime replacement of suspension pivot bearings to the original owner
  • Compatible with electronic drivetrains only
    Specification
    FRAMESET
    SWAT
    SWAT 4.0 internal downtube storage
    Frame
    FACT 11m carbon chassis and rear-end, Trail Geometry, SWAT Door integration, head tube angle adjustment, threaded BB, internal brake and dropper cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel
    Seat Binder
    Alloy, 38.6mm
    SUSPENSION
    Fork
    hlins RXF38 M.2 29, TTX Twin Tube Damping, external low speed rebound adjust, external high and low speed compression adjustment, 15x110mm, 44mm offset, 160mm of travel
    Rear Shock
    hlins TTX 22 M Coil, Ride Dynamics trail tune, external rebound adjust, external high and low speed compression adjustment, 210x55
    COCKPIT
    Saddle
    Bridge Comp, Hollow Cr-mo rails, S1-S2: 155mm, S3-S6: 143mm
    Stem
    Deity, 35mm clamp, 35mm length
    Grips
    Diety, Supracush, Black
    Handlebars
    Deity, Racepoint, 5-degree upsweep, 9-degree backsweep, 810 width, S2: 25mm rise; S3-S6: 38mm rise
    SeatPost
    PNW Loam OE Dropper, tool-less travel adjust, Range lever, 34.9, S2: 150mm, S3: 170mm, S4-S6: 200mm
    BRAKES
    Front Brake
    TRP DH-R EVO, 4-piston caliper, hydraulic disc, 220mm
    Rear Brake
    TRP DH-R EVO, 4-piston caliper, hydraulic disc, 203mm
    DRIVETRAIN
    Chain
    SRAM GX Eagle Transmission Flattop Chain
    Cassette
    SRAM GX Eagle Transmission Cassette, 12spd, 10-52t
    Bottom Bracket
    SRAM DUB, BSA 73mm Wide, Threaded
    Shift Levers
    SRAM AXS POD Controller
    Crankset
    SRAM GX Eagle Crankset, 32T ring, 55mm Chainline, S2-S3:165mm, S4-S6: 170mm
    Rear Derailleur
    SRAM GX Eagle Transmission Derailleur
    WHEELS & TIRES
    Rims
    Roval Traverse, hookless alloy, 30mm inner width, tubeless ready, Front: 29, Rear: 27.5
    Front Hub
    DT Swiss 370, 15x110mm, 28h
    Front Tire
    Butcher, GRID TRAIL casing, GRIPTON T9 compound, 2Bliss Ready, 29x2.3"
    Rear Hub
    DT Swiss 370, 12x148mm, 32h
    Rear Tire
    Eliminator, GRID GRAVITY casing, GRIPTON T9/T7 compound, 2Bliss Ready, 27.5x2.3"
    Spokes
    Sapim Force
    Inner Tubes
    Standard, Presta valve
    PRODUCT DETAILS
    Product ID
    221405
    WEIGHT
    Weight
    15.30kg (33 lb, 11.7 oz)
    Weight Size
    S4
    Geometry

    S2S3S4S5S6
    Crank Length165165170170170
    Handlebar Width810810810810810
    Stem Length3535353535
    Saddle Width155143143143143
    Seatpost Length150170200200200
    Stack621630644657671
    Reach420445470495525
    Headtube Length100110125140155
    Headtube Angle6464646464
    BB Height340340340340340
    BB Drop3535353535
    Trail134134134134134
    Fork Length (full)573573573573573
    Fork Rake/Offset4444444444
    Front Center755785816848884
    Chainstay Length432432432442442
    Wheelbase11861216124712881325
    Top-tube Length (horizontal)574596625649678
    Bike Standover Height751745745745751
    Seat Tube Length385405425445465
    Seat Tube Angle7676.576.576.877.2
    Max Seatpost Insertion245255255285285
    Min Seatpost Insertion8080808080
