Description
Begging for your input, chomping to respond. flick it, pedal it, pump it to the moon. a stoke-making mutation of fun-focused DNA, blinding proof that less can be a whole lot more. Come out to play. You bet your ass the SB135 is still down.
Specification
TRAVEL 135MM (5.3")
MATERIAL TURQ SERIES
FORK FOX FACTORY 36 FIT4
SHOCK FOX FACTORY FLOAT
WHEELSET RACEFACE ARC OFFSET 30MM/DT SWISS 350
REAR DER SRAM X01 EAGLE
SHIFT SRAM X01 EAGLE
CRANK SRAM X1 EAGLE CARBON 30T 170MM
BB SRAM DUB BSA 73
CASSETTE SRAM X01 EAGLE 1295 10-52
CHAIN SRAM GX EAGLE
BRAKES SRAM G2 RSC
ROTOR F/R SRAM CENTERLINE 180/SRAM CENTERLINE 180
POST FOX TRANSFER 31.6MM / XS: 125MM, SM: 150MM, MD: 175MM, LG-XL: 200MM
TIRE (F) MAXXIS MINION DHF 2.6 EXO
TIRE (R) MAXXIS REKON 2.6 EXO
HEADSET CANE CREEK 40 INTEGRATED
BAR YETI CARBON 35X760MM
STEM BURGTEC ENDURO MK3 35X50MM
GRIPS ODI ELITE PRO
SADDLE SILVERADO CUSTOM
Geometry
| XS | SM | MD | LG | XL | ||
| A | SEAT TUBE LENGTH | 13.6 | 14.4 | 15.7 | 17.3 | 18.5 |
| B | TOPTUBE LENGTH | 21 | 22.3 | 23.5 | 24.4 | 25.5 |
| C | HEADTUBE ANGLE | 65.5 | 65.4 | 65.4 | 65.4 | 65.4 |
| D | EFF. SEAT TUBE ANGLE | 77 | 77 | 77 | 77 | 76.9 |
| E | ACTUAL SEAT TUBE ANGLE | 72.1 | 72.4 | 72 | 72.1 | 72.3 |
| F | CHAINSTAY LENGTH | 16.9 | 17 | 17 | 17.1 | 17.2 |
| G | WHEELBASE | 44.9 | 45.8 | 47.2 | 48.2 | 49.5 |
| H | ESTIMATED BB HEIGHT | 13.3 | 13.3 | 13.3 | 13.3 | 13.3 |
| I | STANDOVER | 26.6 | 26.7 | 28.1 | 28.2 | 28.4 |
| J | HEADTUBE LENGTH | 3.6 | 4.0 | 4.2 | 4.6 | 5.1 |
| K | AXLE TO CROWN | 21.6 | 21.6 | 21.6 | 21.6 | 21.6 |
| L | OFFSET | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 |
| M | STACK | 23.0 | 23.3 | 23.5 | 23.9 | 24.3 |
| N | REACH | 15.7 | 16.9 | 18.1 | 18.9 | 19.9 |
| O | FRONT CENTER | 27.5 | 28.9 | 30.1 | 31.1 | 32.3 |
| P | Vertical Fork Travel | 5.7 | 5.7 | 5.7 | 5.7 | 5.7 |
