DESCRIPTION
- POWERFUL AND NEW RECORD-BREAKING INTEGRATED RANGE: THE BOSCH PERFORMANCE CX (SMART SYSTEM) E-DRIVE WITH NEW KIOX 300 DISPLAY AND INTEGRATED, REMOVABLE BATTERY OFFERS 750 WH
- 130 MM TRAVEL WITH NEW F.O.L.D. KINEMATICS OPTIMIZED FOR MORE PROGRESSION: FOX BRAND NEW 34 SUSPENSION FORK AND FOX FLOAT DPS REAR SHOCK
- HIGH PRECISION AND EXTREME RELIABILITY: SHIMANO XT 1X12 SHIFTING AND STRONG SHIMANO XT 4-PISTON BRAKES
MORE THAN JUST TRAILS
SUPER POWERFUL AND DYNAMIC E-MOTOR WITH RECORD-BREAKING INTEGRATED RANGE
The efficient Bosch Performance CX e-drive (Gen. 4) supports your ride up to 32 km/h with powerful 85 Nm. The strongest e-motor of Bosch is perfectly integrated, the THRON rides well-balanced. In eMTB mode, the motor support adjusts automatically to your riding power. The new 750 Wh battery (smart system) delivers endless tail fun. The battery is integrated into the down tube, yet removable for charging. On top, you get the new Kiox 300 display with the new LED remote.
OPTIMIZED KINEMATICS FOR STRONG PROGRESSION
With the upgrade of our well-known F.O.L.D. kinematics, your THRON 6.9 is ready for even more fun on your tours. We kept the well-liked sensitivity of the F.O.L.D. but changed the positioning of our kinematics within the frame for strong bottom-out resistance. The characteristics are completely progressive which results in a chassis that offers a lot of stability making you feel safe on any terrain. Especially e-mountain bikes with their additional weight of motor and battery benefit from more progression. This allows you to handle any trail while the chassis still provides comfort for long laps. Furthermore, the lower standover of the THRON 6.9 gives you more space to play on the trail.
DIVERSE USAGE
From trail tours through alpine terrain to your daily commute and bikepacking: anything is possible with the THRON. With certain changes to the build, you can add various features to your THRON depending on where your e-MTB tour is going. Furthermore, the specially developed C.I.S. (Cockpit Integration Solution) design ensures a clean cockpit and constantly seamless shifting and braking. All cables run from the handlebar into the stem and through the headset into the frame. Additionally, a USB C port on the top tube gives you the opportunity to charge your devices.
| FRAME | 7005 hydroformed aluminium, 3D forging, 130mm F.O.L.D. kinematics, 148x12 mm thru-axle, USB-C port, post mount 180 mm |
| FRAME MATERIAL | Aluminium |
| FORK | FOX 34 Float Rhythm 29, E-Bike, Grip Remote, 110x15 mm, 46 mm rake |
| TRAVEL FORK | 130 mm |
| SHOCK | FOX Float DPS, 210/50 mm, hardware: 25.0 x 8.0 mm, no Bushing |
| MOTOR | Bosch Performance CX Smart, 85 Nm, 250 W |
| BATTERY WATT-HOURS | 750 Wh |
| BATTERY AMPERE HOURS | 20,8 Ah |
| DISPLAY | Bosch LED Remote Kiox 300 |
| SHIFTER | Shimano Deore XT SL-M8100, 12-speed |
| REAR DERAILLEUR | Shimano Deore XT M8100, 12-speed |
| SPROCKET | Shimano SLX M7100, 12-speed |
| CHAIN | Shimano SLX CN-M7100, 12-speed |
| CRANKSET | Samox EC40 ISIS |
| TRANSMISSION OF DRIVE | Front: 34T, Rear: 11-51T |
| BOTTOM BRACKET | Integrated in Drive Unit |
| HANDLEBAR | Aluminium, 800 mm, rise: 30 mm, backsweep: 9 |
| STEM | FOCUS C.I.S. integrated, 50 mm, 0, 35 mm, aluminium |
| HEADSET | ACROS ZS56/ZS56 (ICR), FOCUS C.I.S. Integrated |
| SADDLE | Proxim X400 |
| SEATPOST | Post Moderne dropper post PM-214, 34.9 mm |
| BRAKES | Shimano MT520, hydraulic disc brake |
| BRAKE LEVER | Shimano MT520 |
| BRAKE | Disc |
| WHEELSET | DT SWISS H1900, 30-622, 15x110 mm / 12x148 mm |
| TIRES | Schwalbe Hans Dampf, 2.6 SuperGround Soft, 65-622 |
| REAR TIRE | Schwalbe Nobby Nic 2.6 SuperTrail SpeedGrip |
| GEARS | 12 |
| BIKE WEIGHT INCL. BATTERY | 26,60 kg |
| SHIFTING TYPE | Mechanical shifting |
| SIZE | M, L, XL |
Speed limit for e-support in New Zealand is 32 km/h. Our e-bikes are adjusted accordingly.
*Subject to technical modification without notice. Errors and omissions excepted.
** Weight in size M, of standard specification and without pedals.
